Produktnummer:
10175314
Herstellernummer:
226-KT-50-M10
Hersteller:
Ganter
Ganter 226-KT-50-M10 GRIFFSCHEIBE (THERMOPLAST)
Bohrung (d3):
-
Gewinde (d2):
M 10
Handraddurchmesser (d1):
50
| Anzahl | Preis* |
|---|---|
| Bis 110 |
3,38 €
|
| Bis 155 |
3,04 €
|
| Bis 199 |
2,70 €
|
| Ab 200 |
2,37 €
|
Produktnummer:
10175314
GN 226 Griffscheiben
Beschreibung
Griffscheiben GN 226 sind Bedienungselemente, die sowohl für Verstell- als auch Spannvorgänge eingesetzt werden können.
Ausführung:
• Kunststoff KT
Thermoplst (Polyamid PA)
--schlagfest
--schwarz, matt
• Nabe
Stahl, brüniert
Auf Anfrage:
• ohne Nabenbohrung
Ausführung:
• Kunststoff KT
Thermoplst (Polyamid PA)
--schlagfest
--schwarz, matt
• Nabe
Stahl, brüniert
Auf Anfrage:
• ohne Nabenbohrung
Eigenschaften
| Bohrung (d3): | - |
|---|---|
| Gewinde (d2): | M 10 |
| Handraddurchmesser (d1): | 50 |
| Werkstoff: | KT |
Dokumente
1
| Variante | Gewinde (d2) | Handraddurchmesser (d1) | Bohrung (d3) | Preis |
|---|---|---|---|---|
|
10175314 (226-KT-50-M10) |
M 10 | 50 | - | ab 3,38 € |
|
10175315 (226-KT-50-B8) |
- | 50 | B 8 | ab 3,62 € |
|
10175316 (226-KT-50-B10) |
- | 50 | B 10 | ab 3,62 € |
|
10175318 (226-KT-50-M8) |
M 8 | 50 | - | ab 3,62 € |
|
10175317 (226-KT-63-M10) |
M 10 | 63 | - | ab 4,21 € |
|
10175319 (226-KT-63-M12) |
M 12 | 63 | - | ab 4,21 € |
|
10175321 (226-KT-63-B10) |
- | 63 | B 10 | ab 4,23 € |
|
10175322 (226-KT-63-B12) |
- | 63 | B 12 | ab 4,23 € |
|
10175320 (226-KT-80-B16) |
- | 80 | B 16 | ab 6,50 € |
|
10175323 (226-KT-80-M16) |
M 16 | 80 | - | ab 6,50 € |
|
10175324 (226-KT-80-B12) |
- | 80 | B 12 | ab 6,50 € |
